1. 3ph/220V input power allows even 160A cutting capacity.
2. Able to be connected with CNC equipment to achieve automatic cutting function; the connector is optional.
3. MULTI-FUNCTION two in one, optional MMA function.
4. Powerful cutting capacity, narrow cutting seam, and clean cutting edge.
5. 2T/4T self-locking function.
6. Pilot Arc Starting increases cutting capability and cutting speed, improving the service life of torch kit.
7. Heavy-duty cycle for industrial use.
Excellent performance for the priceIt is a durable plasma cutterPowerful plasma welding| Model | CUT-60PRO |
|---|---|
| Power input AC(V) | 3ph 220V /380V ±15% |
| Power input frequency(Hz) | 50/60 |
| Max. Load Power Capacity | 15.0 kVA |
| Rated current input(A) | 39.35 |
| Rated output current(A)/voltage(V) | 60/104 |
| Max. cutting current (A) | 60 |
| Open circuit voltage DC(V) | 280 |
| Rated duty cycle(%) | 60 |
| Max.cutting thickness(mm) | 20 |
| IP grade | IP21 |
| Insulation grade | F |
| Dimensions(mm) | 530*315*430 |
| Weight (KG) | 13 |
Video
