ARC-160CS Stick Welder – MMA and Lift TIG for Precision Welding

Discover the unparalleled welding performance of the ARC-160CS Stick Welder, a versatile tool designed to meet all your welding needs. This welder seamlessly combines both MMA and lift TIG functions, offering advanced control technology for exceptional welding results.

With the capability to handle various welding applications, the ARC-160CS is equipped with advanced control technology, ensuring superior welding performance. Weld continuously with a 5.0mm electrode for extended periods, thanks to the long-time continuous welding feature.

In Stock
Share (0)
Total: 0 Total: 0 Total: 0 Total: 0 Total: 0 Total: 0 Total: 0 Total: 0

Discover the unparalleled welding performance of the ARC-160CS Stick Welder, a versatile tool designed to meet all your welding needs. This welder seamlessly combines both MMA and lift TIG functions, offering advanced control technology for exceptional welding results.

With the capability to handle various welding applications, the ARC-160CS is equipped with advanced control technology, ensuring superior welding performance. Weld continuously with a 5.0mm electrode for extended periods, thanks to the long-time continuous welding feature.

Features：

1. Both MMA and lift TIG function.
2. Advanced control technology is used to meet various welding applications and greatly improve welding performance.
3. Long-time continuous welding of 5.0mm electrode.
4. Automatic current compensation ensures smooth cellulose electrode(E6010/E6011/E6013) welding.
5. VRD function, guarantees operation safety.
6. External adjustable hot start and arc force.

What’s Included：

2.0m(L) cable with 300A ground clamp
2.0m(L) cable with 200A electrode holder
Welding mask/steel brush with hammer (1pc)

Model

ARC-160CS Stick Welder
Power input AC(V)

1pH 110V/220V ±15%
Power input frequency(Hz)

50/60
Max. Load Power Capacity(kVA)

6.5
Rated current input(A)

38.6
Rated output current(A)/voltage(V)

120/24.8 (110V) 160/27.2 (220V)
Welding current range(A)

20~120 (110V) 20~160 (220V)
Open circuit voltage DC(V)

93
Rated duty cycle(%)

45%
IP grade

IP21S
Insulation grade

F
Dimensions(mm)

430*260*285
N.M./G.W.(kg)

5.1/7.3
